Features

• High strength and firm structure

The main body of the cone crusher a box shaped cast steel structure, whose high load areas are reinforced by hard steel.

• Finite element design

WL series high efficiency cone crusher is designed with the help of modern CAD technology. All series models have gone through the FEM technology analysis, which ensures all stress levels inside within appropriate range and guarantees the high strength structure and stable performance of WL series high efficiency cone crusher.

• High reliability and practicability originates from excellent design

High efficiency compound cone crusher adopts tapered roller bearing to replace the old style horizontal shaft copper sleeve at both ends of the horizontal drive shaft and thus largely improves its rotation speed. Dust proof ring is assembled between the mantle cone and the seat liner. The maze O-ring is full of lubrication oil. The dust proof ring is supported by the spring in the seat liner so as to prevent dust from entering. The machine adopts electric automatic lubrication system that connects the main motor. If the pressure is insufficient or the temperature is too high, the main motor stops immediately to prevent the main engine from damage. The machine is installed with hydraulic pressure adjustment device so as to quickly adjust the discharge mouth size and clear the crushing chamber and therefore reduce the time of machine hault.

• High capacity,low cost and easy

Our machine's fine crushing chamber shape increases the effective crushing surface. The machine has the capacity to process larger feed size, increases 1/3 production capacity comparing with other cone crushers and can produce fine particles and cubic products. The mantle core and the crushing chambre are processed by digital control CNC machine, which makes the replacement of wearing plates quick and easy, eliminates the need to fill epoxide resin and improves the operational efficiency. Traditional cone crusher with the ancient crushing chamber structure, has limited crushing surfaces, low production and produces more elongated and flaky particles content. Epoxide resin needs to be filled between the mantle cone the crushing surface, which makes the replacement difficult, increases the failure rate and machine halt time and causes unstable performance of the machine.

• Less downtime

Using the Hydraulic Pressure Chamber Clearing mean the WL Series cone crushers can pass tramp iron that would stall many competitors’ crushers. Using the Hydraulic Pressure Adjustment Device setting adjustment with the adjustment under load capability makes it easy to balance the crushing circuit and optimize crusher productivity.
